Chelate Iron Desulfurization H2s Removal Scrubber for Syngas

Get top-quality chelate iron desulfurization scrubbers for syngas H2S removal from our factory. Achieve efficient and reliable gas purification solutions.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Hydrogen Sulfide Removal
Condition
New
Certification
RoHS, ISO
Capacity
Larger Than 5000m3/Day
Processing Method
Biological Method
Temperature
Normal
Material
Fiber Reinforced Plastic
Service Time
30 Years
Control
Automatic
Technical Support
Available
Reduced H2s Concentration
100-200ppm
Initial H2s Concentration
100ppm~50000ppm
Transport Package
Standard Export Packing
Specification
Customized
Trademark
Mingshuo
Origin
China
HS Code
84213990
Production Capacity
100 Sets/Year

Product Description



Chelate Iron Desulfurization H2s Removal Scrubber for Syngas
Chelate iron desulfurization H2S removal scrubber for syngas


Adopted international advanced technology, the new desulfurization device is uniquely designed and produced by our company in China. Iron-based wet desulfurization is a miniature high-efficiency desulfurization device independently developed by our company. It's designed with all-stainless steel structure, using an iron-based nutrient desulfurization liquid which is developed and produced by our company as catalyst, suitable for desulfurization of hydrogen sulfide containing gas.

It has the characteristics of no pollution, low energy consumption, no need to consume alkali, high desulfurization precision, no need for secondary desulfurization, simple operation, long service life and by-product sulfur. The device can be mobile
 and skid-mounted, possible to be used or transported in container, widely used in the desulfurization of gases such as biogas, natural gas and oilfield associated gas.

Chelate Iron Desulfurization H2s Removal Scrubber for Syngas
Iron-based nutrient solution desulfurization technology has the following advantages compared with other traditional chemical desulfurization and biological desulfurization:
Iron-based nutrient solution desulfurization technology has large working sulfur capacity, large flexibility, skid-mounted, low equipment investment, low desulfurization cost, low power consumption, no waste liquid discharge, high operational stability, and high removal rate for COS, thiol organic sulfur etc.

Product specifications:
Name: Iron-based nutrient solution catalyst
Iron content: ≥ 2.5% (based on Fe element)
Working sulfur capacity: 8.5g / L
Inorganic salts: ≤0.2% (in cl¯, so42- meter)

Chelate Iron Desulfurization H2s Removal Scrubber for Syngas
Comparison Dry Desulfurization Wet Desulfurization Micro Wet Desulfurization Biological Desulphurization
Application Small and medium projects with gas less than 5000m³/day; Second high precision desulfurization after other methods Large Gas Plant up to 100,000 m^3/ day; High sulfur content around 5g/Nm³ Large-scale Large-scale, high sulfur-containing gas (100ppm~20000ppm)
Power Consumption None High Moderate Moderate
Operating Cost Moderate, the desulfurizer need to be changed periodically Moderate Low Low cost on electricity bill
Land Scale Small Full set of equipment for gas desulfurization, regeneration, filtration and melting sulfur, in result, large land is required. Moderate Moderate
Operation Management Easy to manage, reliable operation, dispense with staff on duty Need people on duty to control the operation Automatic operation, simple maintenance Automatic operation, simple maintenance
Remarks Refueling at fixed period, one use one reserve, alternate operation Many equipment Less equipment than wet desulfurization
Advantages Simple structure, low investment, long lifetime, high precision of desulfurization (lower than 15ppm) It can deal with large amount gas, and the system can run continuously by using PH value to keep the efficiency. High efficiency by Iron Chelate, small in size, and high processing capacity High desulfurization efficiency 99.5%, no second pollution, stable performance, suitable for large-scale, high sulfur-containing gas

Management System Certification: ISO9001:2008, ISO14001:2004, OHSAS18001:2007
