Basic Info.
Model NO.
WFS
Specification
carbon steel
Trademark
BETTER
Origin
China
Production Capacity
1300sets/Year
Product Description
Product Description
Incineration has particularly strong benefits for the treatment of certain waste types in niche areas such as clinical wastes and certain hazardous wastes where pathogens and toxins can be destroyed by high temperatures.
To better serve our customers, we delivered a kind of small size incinerator that was capable of handling all types of waste material - so one machine could safely incinerate household waste from the hospital and waste from the surgical process.
To better serve our customers, we delivered a kind of small size incinerator that was capable of handling all types of waste material - so one machine could safely incinerate household waste from the hospital and waste from the surgical process.
Size Information
| Model | WFS-30 | WFS-50 | WFS-150 | WFS-300 | WFS-500 |
| Burning Capacity | 20-30kg/time (3-6 times/day) | 30-50kg/time (3-6times/day) | 100-150kg/time (3-6times/day) | 200-300kg/time (3-6times/day) | 300-400kg/time(3-6times/day) |
| Incinerator Size m (L*H*B) | 1.45*0.9*1.75 | 1.8*1.15*3 | 2*1.4*3.5 | 2.2*1.4*3.8 | 3*2*4.8 |
| Imputing Mouth Width (mm) | 480*600 | 620*800 | 760*960 | 900*1100 | 1080*1280 |
| Chimney External Diameter (mm) | 280 | 280 | 300 | 400 | 460 |
| Draught Fan | 0.37kw | 0.37kw | 0.5kw | 1.1kw | 1.1kw/0.55kw |
| Combustion Improver Device | 0.11kw Oil consumption: 4-6kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.22kw Oil consumption: 7-14kg/h | 0.22kw Oil consumption: 7-14kg/h |
| Re-Burning Device | 0.11 kw Oil consumption 4-6 kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.22kw Oil consumption: 7-14kg/h | 0.37kw Oil consumption: 10-20kg/h | 0.37kw Oil consumption: 15-26kg/h |
| Voltage | 380v/220v | 380v/220v | 380v/220v | 380v/220v | 380v/220v |
Direction for use
Waste incineration includes the following:
Infectious waste: blood and bodily fluids ,bacterias and stocks of infectious agents from laboratory work , or waste from patients in isolation wards . Pathological waste: human tissues, organs or fluids, and contaminated animal carcasses;
Sharps: syringes, needles, disposable scalpels and blades, etc.;
Chemicals: for example solvents used for laboratory preparations, disinfectants, and heavy metals contained in medical devices
Pharmaceuticals: expired, and contaminated drugs and vaccines
Description of application effect
Infectious waste: blood and bodily fluids ,bacterias and stocks of infectious agents from laboratory work , or waste from patients in isolation wards . Pathological waste: human tissues, organs or fluids, and contaminated animal carcasses;
Sharps: syringes, needles, disposable scalpels and blades, etc.;
Chemicals: for example solvents used for laboratory preparations, disinfectants, and heavy metals contained in medical devices
Pharmaceuticals: expired, and contaminated drugs and vaccines
Description of application effect
Our standard incinerator range is designed in a way that all exhaust gas has to pass through a secondary burner for complete re-burn of harmful gas components. Exhaust gases are then retained for a period of time at a high temperature (850 - 1200°C, depending on the application). This is what we call 'Basic' pollution control.
Dioxins, furans and similar gaseous components are only destroyed by :
Homogeneous high temperature (> 850°C)
Dioxins, furans and similar gaseous components are only destroyed by :
Homogeneous high temperature (> 850°C)
Excess of oxygen (>6 %)Sufficient residence time at high temperature
Technical Support:
1). 3D operation video
2). English manual book
3). Technical drawing
4). Experienced engineers guide
BETTER manufactures incinerator for a number of different industries, and we specialize in designing reliable incinerator for the hospital, food, energy and marine industries. Our trained engineers have many years of experience, thus we are able to offer custom-made incinerators for a wide variety of sectors with very different needs.
