Basic Info.
Model NO.
LCS series
Type
Desander
Transport Package
Exported Package
Specification
customized
Trademark
Hondin
Origin
China
Production Capacity
2000 Pieces/Year
Product Description
LCS series desander is the second solids control system in well drilling, the general cones are8",10",and 12", mainly separate 47~76μm particle out. According to customers treating capacity requirements, choose use how many cones.
| Model | LCS250×2 | LCS300×2 |
| Capacity | ≤240mm³/ ≤1056GPM | ≤300mm³/h / ≤1320GPM |
| Cone size | 250mm/10'' | 300mm/12'' |
| Cone Number | 1~2 Ea Cones,specify cones No. when ording | |
| Pressure | 0.21~0.4Mpa | 0.21~0.4Mpa |
| Maching pump | 37kw/55kw | 55kw/75kw |
| Inlet size | 150mm | 150mm |
| Outlet size | 200mm | 200mm |
| Separation size | 45-75μm | 45-75μm |
