Product Description
Zeolite molecular sieves have the structure and characteristics of crystals, the surface is a solid skeleton, and the internal holes have the function of adsorbing molecules. There are pores connected to each other, and molecules pass through the pores channels. Due to the crystalline nature of the pores, the pore size distribution of molecular sieves is very uniform. Molecular sieves selectively adsorb molecules according to the size of the holes in their crystal, that is, they adsorb molecules of a certain size and repel molecules of larger substances, so they are figuratively called "molecular sieves."
The X-type molecular sieve 13X has a much larger pore opening than the A-type. It is mainly used for the purification of raw gas in air separation plants to remove water and carbon dioxide; the drying and desulfurization of LNG, liquefied petroleum gas, and liquid hydrocarbons; and the deep drying of general gases.
Molecular sieves 13X HP oxygen enriching molecular sieve is a new type X molecular sieve for PSA oxygen concentrator. They are widely used as catalysts to remove the nitrogen from oxygen to obtain pure oxygen. which has higher N2 adsorption capacity and better effect in the N2 /O2 separation process. It's also used as a desiccant agent to absorb the water, moisture, and humidity from liquids, oils and gases.
| Properties | Unit | Technical data | |||
| Shape | Spherical | Cylindrical | |||
| Diameter | mm | 1.6~2.5 | 3.0~5.0 | 1.5~1.7 | 3.0~3.3 |
| Granularity | % | ≥97 | ≥97 | ≥98 | ≥98 |
| Bulk Density | g/ml | ≥0.65 | ≥0.61 | ≥0.61 | ≥0.60 |
| Abrasion | % | ≤0.20 | ≤0.20 | ≤0.20 | ≤0.20 |
| Crush Strength | N | ≥35 | ≥90 | ≥30 | ≥50 |
| Static H2O Absorption | % | ≥28 | ≥28 | ≥28 | ≥28 |
| CO2 Adsorption | NL/g | ≥18 | ≥18 | ≥18 | ≥18 |
| Moisture | % | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
13X Molecular Sieve Application Fields
1) Gas purification in the air separation unit to remove water and carbon dioxide.
2) Drying and desulfurization of LNG, liquefied petroleum gas and liquid hydrocarbons.
3) Removal of hydrocarbons.
4) Drying and purification of NH3 synthesis gas.
5) Desulfurization and deodorization of aerosol propellants.
6) Cracking gas deCO2
7) Catalyst carrier.
8) Co-adsorption of water and carbon dioxide.
9) Co-adsorption of water and hydrogen sulfide gas.
Package
*25kg Carton with inner PE bag.
*55 Gallon steel drum
*Other packing by customer request
Storage
Prevent the molecular sieves from exposing directly to the damping environment and any absorption of water or organic substance before it's used, otherwise it must be regenerated.
All Chemequip molecular sieves can be regenerated by temperature or pressure swing.
Delivery
For small quantity order < 100kg, 10 days after purchased contract is efficient.
For big quantity order > 500kg, 15 days after purchased contract is efficient.
Chemequip(Xuancheng) New Material Ltd. devotes to provide the optimal custom-made molecular sieves solution to the customers around the world. Its headquarter Chemequip Industries Ltd. located in the Songjiang district, Shanghai of China, has deeply cooperated with an internationally recognized high efficient heat exchange technology supplier for nearly 20 years.
Chemequip (Xuancheng) New Material Ltd. commits to provide the world market with new chemical material molecular sieves product, it sets up the sales and services offices in Europe and an agent service system in the Middle East, providing the optimal solution for global customers.
Chemequip (Xuancheng) New Material Ltd. establishes a molecular sieve production base with an annual output of 20,000 tons in the Xuancheng Economic Development Zone, it covers an area of 35 acres with a factory area of 23,000 m2 and an R&D center of 1500 m2. It can provide molecular sieves types includes the 3A, 4A, 5A, 13X and a variety of high-end formulations such as 13X medium silicon and 13X low silicon, and also it can be customized by customer request.
